Mechanical Properties
- Dimensions (lxwxh) 6.06 x 2.44 x 2.59 (m)
- Weight 3092 kg
- Static Load – 5400 Pa (snow)
- Static Load – 2400 Pa (wind)
Electrical Properties
- Rated Power 10 kW to 60 kW
- 3 Faze options available
- AC Nominal Voltage 400/230/115 V
- Rated frequency/ voltage 50 Hz
- Max Output Current 32 – 180 A
- Operating range −25°C/+60°C
Generator
- Maximum Power 25 KVA
- Rated Power 20 Kw
Energy Storage
- Electricity Storage – From 15 – 100 kWh
- Capacity – From 400 Ah to 2000 Ah
Energy Saving Example
Hiring a basic 25 kW Solatainer® with a 4KW PV array, 15KWh Battery and 13kW standby Generator:
- Deployed Spring 2018 to power a 4 Cabin Site Office
- Fuel Consumption post-Solatainer 209 litres/week
- Reduced CO2 Emissions by 55t/year
- Fuel Consumption pre-Solatatiner 607 litres/week
- Annual saving £11132
Solatainer® – Off grid power supply
Solatainer® has been developed to provide an autonomous off-grid power supply, integrating renewable-power and storage with diesel-power back-up to reduce fuel consumption, carbon emissions and carbon footprint.
Modeled on a 20ft ISO shipping container, Solatainer® supports a PV array specified for maximum solar gain and efficiency. When equipped with Ecoxero’s ground breaking Solawedge® the unit is scale-able up to 200kw and in its standard setup comprises of a 4Kw PV array, 15Kw/h battery pack and 15Kw stand-by generator.
During daytime operation the energy created by Solatainer®’s PV solar panels is harvested and stored in an on-board battery pack. The standby generator is configured to run only when batteries are depleted below a software-set limit or when a demand spike occurs.
The results are spectacular, reducing fuel costs by c80% when compared to a conventional diesel generator.
Why choose Solatainer®
- Reduced Energy Costs
- Reduce Environmental Impact and Carbon Footprint
- Increase Competitive Advantage
- Regulatory Compliance e.g. ISO 14001 And Considerate Constructor
- Enhanced Corporate Image and Reputation for Environmental Stewardship
